Ford Raptor R 4X4 VXL
MODEL SPECS
| Model Name: |
Ford Raptor R 4X4 VXL: 1/10 Scale 4X4 Brushless Replica Truck |
| Model Type: |
Short Course Trucks |
| Model Speed: |
60+ mph with optional gearing and 3s LiPo battery (items sold separately) |
| Model Skill Level: |
2 |
| Scale: |
1/10 |
| Weight: |
6.05 pounds (2.74 kg) |
| Length: |
24.98 inches (637 mm) |
| Width: |
11.63 inches (289 mm) |
| Front Track: |
11.63 inches (289 mm) |
| Rear Track: |
11.63 inches (289 mm) |
| Height: |
8.91 inches (226 mm) |
| Wheelbase: |
15.11 inches (384 mm) |
| Center Ground Clearance: |
2.05 inches (52 mm) |
| Drive System: |
Shaft-driven 4WD |
| Drivetrain: |
Shaft-driven 4WD |
| Differential Type: |
Hardened steel bevel, sealed, limited slip |
| Gear Pitch: |
32 pitch |
| Servo(s): |
2075 high-torque waterproof |
| Radio System: |
TQi 2.4 GHz 2-channel radio |
| Battery Compartment Specs: |
165 mm X 50 mm X 23/26 mm |
MOTOR SPECS
| Motor Name: |
Velineon3500 |
| Motor Type: |
Sensorless brushless |
| Motor Weight: |
9.24 ounces (262 g) |
| Motor Length: |
3.03 inches (77 mm) overall length, 2.2 inches (56 mm) can length |
| Motor Diameter: |
1.41 inches (36 mm) |
| Motor Shaft Size: |
3 mm |
| Motor Connector Type: |
3.5 mm bullet |
ESC SPECS
| ESC Name: |
VXL-3s electronic speed control |
| ESC Type: |
Brushless |
| ESC Case Size: |
1.54 inches (39 mm) / 2.18 inches (55 mm) / 1.30 inches (33 mm) |
| ESC Weight: |
3.17 ounces (90 g) |
| Motor Connectors: |
3.5 mm bullet |
| Battery Connectors: |
Traxxas High-Current Connector |
| ESC Power Wire: |
12 gauge MaxxCable |
- Officially Licensed FordF-150Raptor R Pro ScaleClipless Body and Graphics
- Molded scale details: bumpers, grille, tailgate, side mirrors, and hood vent
- LED lighting in front and rear bumpers
- Body reinforcements to prevent pull-through damage
- Clipless Body Mounting
- Holds tight for intense action
- Quick and easy removal
- Smooth appearance with no body posts or clips
- Extreme Heavy-Duty Upgrade Kit Installed
- Made from our toughest cold-weather resistant composite
- Strengthened C-hubs, axle carriers, steering blocks, and shock towers
- Extreme heavy-duty driveshafts
- Oversize diameter
- 6 mm axles
- Steel wheel hexes
- VXL-3s Waterproof Electronic Speed Control
- Cooling fan with large heat sink
- Three Programmable Drive Profiles
- Sport Mode – Forward / Brake / Reverse
- Race Mode – Forward / Brake
- Training Mode – 50% Forward / Brake / 50% Reverse (patented)
- Traxxas EZ-Setone-button setup
- Built-in two-stage low-voltage detection for LiPo batteries
- NiMH battery packs: 6-9 cells (7.2 to 10.8 volts)
- LiPo battery packs: 2-3 cells (7.4 to 11.1 volts)
- Up to 60+ mph with 3s LiPo battery
- Velineon3500 kV Brushless Motor
- Ultra high-temperature sintered Neodymium magnets
- Optimized for power and efficiency in 1/10th scale vehicles
- Efficient, high-speed ball bearings
- Precision-balanced rotor
- 3500 kV
- Brilliant blue-anodized finish
- Traxxas Stability Management(TSM)
- Improves straight line acceleration and braking on low-traction surfaces
- Maintains steering composure to allow throttle-on powerslides
- Never dulls throttle or slows the truck
- Adjusts from off to 100% assistance from the transmitter
- TQi 2.4 GHz High Output Radio System
- TQi 2-channel transmitter
- Automatically stores and loads settings for up to 30 Traxxas Link-enabled models
- Programmable multi-function knob
- Adjustable steering and throttle percentage (dual rates)
- Adjustable steering and throttle sensitivity (exponential)
- Adjustable steering and throttle end points
- 5-channel micro receiver (6533) with fail-safe security
- Patented waterproof receiver box with easy-access plug
- Chassis
- Extended modular composite tub design
- Secure battery hold-down latch
- Side nerf bars for impact resistance
- Drivetrain
- Full-time shaft-driven 4-wheel drive
- Oil-filled steel gear front and rear differentials
- Large 32-pitch steel spur gear
- Anodized-aluminum center driveshaft
- Steering
- Chassis-mounted 2075 servo
- Dual bellcrank design with integrated servo saver
- Suspension
- Heavy-duty suspension arms
- Adjustable 4 mm steel toe and camber links
- Oil-filled Ultra Shocks
- White powder-coated progressive springs
- Wheels and Tires
- Licensed Fordreplica option wheels
- 2 outer diameter, 3 inner diameter
- Licensed BFGoodrichAll-Terrain T/AKO2 tires
- Larger114 mm diameter
- Sealed Ball Bearings
- Hex hardware with Rust-Resistant Black Oxide Coating
MODEL101076-4:FordF-150Raptor R: 1/10 scale 4X4 short course truck, fully-assembled, waterproof electronics, Ready-To-Race, with TQi 2.4 GHz 2-channel radio system, Traxxas Stability Management (TSM), VXL-3s speed control, and clipless painted Pro Scalebody. Requires: battery and charger.
Whats In The Box:
- Raptor R with Velineon VXL-3s ESC and 3500 kV motor
- Quick Start Guide
- TQi 2.4 GHz radio system
- High quality maintenance tools
What Youll Need:
- Batteries
Raptor R requires a single NiMH or LiPo battery. See full list of batteries.
- Charger
Traxxas EZ-PeakLive charger (2971) is recommended for easy and fast charging performance.
- AA Alkaline Batteries
Four AA alkaline batteries for the transmitter.
