BDS Suspension 4″ Suspension Lift Kit for Dodge Ram 1500 4WD Gasl 1/2 Ton Pickup.

FourWheeler Magazine Tech Story

This 4″ lift kit will clear up to 35″ tires and is based around two one-piece, 1/4″ laser cut high-clearance crossmembers and replacement steering knuckles. The high-clearance crossmembers increase ground clearance for off road performance.

The replacement steering knuckles reduce installation time as well as maintain proper steering angles and ball joint angles. A differential skid plate is included for off road protection.

The system also includes bump stop drops, anti-sway bar links, 3 point differential drop system, strut relocation brackets, and front stainless steel brake lines.

The rear is lifted via BDS 2″ coil spacers to level most trucks. The rear for this Dodge Ram lift kit is completed with a track bar bracket, upper link relocation brackets and sway bar links. A 3″ rear coil spring option is available depending on your desired stance.

Check out more options and build your own kit by clicking on customize this kit.

• Tire & Wheel Combinations
• 35″ x 12.50″ w/17 x 9 and 4-1/2″ back spacing
• 35″ x 12.50″ w/18 or 20 x 9 and 5″ back spacing

*Trimming may be required*

• Est. Installation:10 hours
• Difficulty Level (easy 1 – 5 complicated):4
